ATE-2001
ultimate phono pre-amplifier
Features
- THE PEERLESS
- EQ circuitry configured by 2 NF stages & low-impedance, SRPP output stage assures stable function of NF to achieve low distortion
- Select on-deck step-up transformer to derive the full potentials of MC cartridges
- Low-impedance output created by non-NFb SRPP circuit enables to drive any of power amps
- Abundant inputs, 3 lines & 4 phonos (3 MC + 1 MM) for versatile use. MC impedance selectable between 3Ω & 20Ω
- Low-noise power supply featuring an optimum combination of valve & semi-conductor in pursuit of utter operational stability & noise banishment
- Constant voltage an independent regulator supplies to each valve ensures thorough elimination of mutual interferences
Specs
|
Valves employed:
|
6X4 × 1, EF86 × 1, 12BH7 × 1, 12AX7 × 3, 6922 × 2
|
|---|---|
|
Output voltage:
|
rated 2V, max. 20V
|
|
Output impedance:
|
less than 2k ohms
|
|
THD:
|
less than 0.08%(2V, 1kHz)
|
|
Input sensitivity:
|
1.2mV(phono)
|
|
Input impedance:
|
47k ohms(phono), 100k ohms(line)
|
|
S/N ratio(IHF-A):
|
phono; more than 78dB
line; more than 97dB
|
|
Dimensions:
|
amp section; 400(W) × 320(D) ×140(H)mm
power supply; 400(W) × 320(D) ×140(H)mm
|
|
Weight:
|
8.5kgs(amp section), 9kgs(power supply)
|
